API Gateway Security: Authentication, Rate Limiting, and WAF Configuration

┌─────────────────────────────────────────────────────────────────────────────┐
│                        API GATEWAY SECURITY LAYERS                           │
├─────────────────────────────────────────────────────────────────────────────┤
│                                                                              │
│  Internet ──► CDN/DDoS ──► API Gateway ──► Backend Services                 │
│                              │                                               │
│              ┌───────────────┴───────────────┐                              │
│              │                               │                              │
│              ▼                               ▼                              │
│    ┌──────────────────┐           ┌──────────────────┐                     │
│    │  INGRESS SECURITY │           │ EGRESS SECURITY  │                     │
│    ├──────────────────┤           ├──────────────────┤                     │
│    │ • TLS Termination │           │ • Response filtering│                  │
│    │ • IP Allowlisting │           │ • Header injection  │                  │
│    │ • Rate Limiting   │           │ • Error sanitization│                  │
│    │ • Request Size    │           │ • Audit Logging     │                  │
│    │ • WAF Rules       │           │ • Encryption        │                  │
│    └──────────────────┘           └──────────────────┘                     │
│              │                               │                              │
│              ▼                               ▼                              │
│    ┌──────────────────┐           ┌──────────────────┐                     │
│    │  AUTHENTICATION  │           │  AUTHORIZATION    │                     │
│    ├──────────────────┤           ├──────────────────┤                     │
│    │ • API Keys        │           │ • Scope validation │                   │
│    │ • JWT Validation  │           │ • Role checking    │                   │
│    │ • OAuth/OIDC      │           │ • Resource policies│                   │
│    │ • mTLS            │           │ • Rate limit tiers │                   │
│    └──────────────────┘           └──────────────────┘                     │
│                                                                              │
└─────────────────────────────────────────────────────────────────────────────┘

# kong.yml - Declarative configuration
_format_version: "3.0"

services:
  - name: user-service
    url: http://user-service:8080
    routes:
      - name: user-routes
        paths:
          - /api/v1/users
        strip_path: false

plugins:
  # Global rate limiting
  - name: rate-limiting
    config:
      minute: 100
      hour: 1000
      policy: redis
      redis_host: redis
      redis_port: 6379

  # JWT authentication
  - name: jwt
    config:
      key_claim_name: kid
      claims_to_verify:
        - exp

  # Request size limiting
  - name: request-size-limiting
    config:
      allowed_payload_size: 10  # MB

  # IP restriction
  - name: ip-restriction
    config:
      allow:
        - 10.0.0.0/8
        - 192.168.0.0/16

# Per-service JWT configuration
plugins:
  - name: jwt
    service: user-service
    config:
      key_claim_name: kid
      claims_to_verify:
        - exp
        - nbf
      maximum_expiration: 3600  # 1 hour max token lifetime

consumers:
  - username: mobile-app
    jwt_secrets:
      - key: mobile-app-key
        algorithm: RS256
        rsa_public_key: |
          -----BEGIN PUBLIC KEY-----
          MIIBIjANBgkqhkiG9w0BAQEFAAOCAQ8AMIIBCgKCAQEA...
          -----END PUBLIC KEY-----

plugins:
  # Tiered rate limiting based on consumer
  - name: rate-limiting-advanced
    service: user-service
    config:
      limit:
        - second: 10
          minute: 100
        - second: 50    # Higher tier
          minute: 500
      identifier: consumer
      window_type: sliding
      sync_rate: 10

      # Redis cluster for distributed limiting
      strategy: redis
      redis:
        host: redis-cluster
        port: 6379
        cluster_addresses:
          - redis-1:6379
          - redis-2:6379
          - redis-3:6379

plugins:
  # Validate request against OpenAPI schema
  - name: request-validator
    service: user-service
    config:
      body_schema: |
        {
          "type": "object",
          "properties": {
            "email": {"type": "string", "format": "email"},
            "name": {"type": "string", "minLength": 1, "maxLength": 100}
          },
          "required": ["email", "name"]
        }

  # Add security headers to responses
  - name: response-transformer
    config:
      add:
        headers:
          - X-Content-Type-Options:nosniff
          - X-Frame-Options:DENY
          - Strict-Transport-Security:max-age=31536000

# serverless.yml (Serverless Framework)
service: secure-api

provider:
  name: aws
  runtime: nodejs18.x
  stage: ${opt:stage, 'dev'}

  # API Gateway settings
  apiGateway:
    shouldStartNameWithService: true
    minimumCompressionSize: 1024

functions:
  # Custom authorizer
  authorizer:
    handler: src/authorizer.handler

  # Protected endpoint
  getUsers:
    handler: src/users.get
    events:
      - http:
          path: /users
          method: get
          authorizer:
            name: authorizer
            resultTtlInSeconds: 300
            identitySource: method.request.header.Authorization
            type: token

resources:
  Resources:
    # WAF WebACL
    ApiWafAcl:
      Type: AWS::WAFv2::WebACL
      Properties:
        Name: api-waf-acl
        Scope: REGIONAL
        DefaultAction:
          Allow: {}
        Rules:
          - Name: AWSManagedRulesCommonRuleSet
            Priority: 1
            Statement:
              ManagedRuleGroupStatement:
                VendorName: AWS
                Name: AWSManagedRulesCommonRuleSet
            OverrideAction:
              None: {}
            VisibilityConfig:
              SampledRequestsEnabled: true
              CloudWatchMetricsEnabled: true
              MetricName: CommonRuleSetMetric

          - Name: RateLimitRule
            Priority: 2
            Statement:
              RateBasedStatement:
                Limit: 2000
                AggregateKeyType: IP
            Action:
              Block: {}
            VisibilityConfig:
              SampledRequestsEnabled: true
              CloudWatchMetricsEnabled: true
              MetricName: RateLimitMetric

// src/authorizer.js
const jwt = require('jsonwebtoken');

const JWKS_URI = process.env.JWKS_URI;
const ISSUER = process.env.JWT_ISSUER;
const AUDIENCE = process.env.JWT_AUDIENCE;

// Cache JWKS
let jwksCache = null;
let jwksCacheTime = 0;
const CACHE_TTL = 3600000; // 1 hour

async function getSigningKey(kid) {
  if (!jwksCache || Date.now() - jwksCacheTime > CACHE_TTL) {
    const response = await fetch(JWKS_URI);
    jwksCache = await response.json();
    jwksCacheTime = Date.now();
  }

  const key = jwksCache.keys.find(k => k.kid === kid);
  if (!key) throw new Error('Key not found');

  return jwt.createPublicKey({ key, format: 'jwk' });
}

exports.handler = async (event) => {
  try {
    const token = event.authorizationToken.replace('Bearer ', '');

    // Decode header to get key ID
    const decoded = jwt.decode(token, { complete: true });
    if (!decoded) {
      return generatePolicy('user', 'Deny', event.methodArn);
    }

    // Get signing key
    const signingKey = await getSigningKey(decoded.header.kid);

    // Verify token
    const verified = jwt.verify(token, signingKey, {
      issuer: ISSUER,
      audience: AUDIENCE,
      algorithms: ['RS256']
    });

    // Generate allow policy with context
    const policy = generatePolicy(verified.sub, 'Allow', event.methodArn);
    policy.context = {
      userId: verified.sub,
      email: verified.email,
      scopes: verified.scope || ''
    };

    return policy;

  } catch (error) {
    console.error('Authorization failed:', error.message);
    return generatePolicy('user', 'Deny', event.methodArn);
  }
};

function generatePolicy(principalId, effect, resource) {
  return {
    principalId,
    policyDocument: {
      Version: '2012-10-17',
      Statement: [{
        Action: 'execute-api:Invoke',
        Effect: effect,
        Resource: resource
      }]
    }
  };
}

# CloudFormation / SAM template
Resources:
  ApiKey:
    Type: AWS::ApiGateway::ApiKey
    Properties:
      Name: partner-api-key
      Enabled: true

  UsagePlan:
    Type: AWS::ApiGateway::UsagePlan
    Properties:
      UsagePlanName: partner-plan
      Throttle:
        BurstLimit: 100
        RateLimit: 50
      Quota:
        Limit: 10000
        Period: MONTH
      ApiStages:
        - ApiId: !Ref ApiGateway
          Stage: prod

  UsagePlanKey:
    Type: AWS::ApiGateway::UsagePlanKey
    Properties:
      KeyId: !Ref ApiKey
      KeyType: API_KEY
      UsagePlanId: !Ref UsagePlan

# /etc/nginx/conf.d/api-gateway.conf

# Rate limiting zones
limit_req_zone $binary_remote_addr zone=api_limit:10m rate=10r/s;
limit_req_zone $http_x_api_key zone=api_key_limit:10m rate=100r/s;
limit_conn_zone $binary_remote_addr zone=conn_limit:10m;

# Upstream backends
upstream user_service {
    zone user_service 64k;
    server user-service-1:8080 weight=5;
    server user-service-2:8080 weight=5;
    keepalive 32;
}

# API key validation map
map $http_x_api_key $api_client_name {
    default "";
    "key_abc123" "mobile-app";
    "key_def456" "web-app";
    "key_ghi789" "partner-app";
}

server {
    listen 443 ssl http2;
    server_name api.example.com;

    # TLS configuration
    ssl_certificate /etc/nginx/ssl/fullchain.pem;
    ssl_certificate_key /etc/nginx/ssl/privkey.pem;
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers ECDHE-ECDSA-AES256-GCM-SHA384:ECDHE-RSA-AES256-GCM-SHA384;

    # Security headers
    add_header X-Content-Type-Options "nosniff" always;
    add_header X-Frame-Options "DENY" always;
    add_header Strict-Transport-Security "max-age=31536000" always;

    # Request size limits
    client_max_body_size 10m;
    client_body_buffer_size 128k;

    # Timeouts
    proxy_connect_timeout 10s;
    proxy_read_timeout 30s;
    proxy_send_timeout 30s;

    # API key validation
    location /api/ {
        # Require API key
        if ($api_client_name = "") {
            return 401 '{"error": "Missing or invalid API key"}';
        }

        # Rate limiting
        limit_req zone=api_key_limit burst=20 nodelay;
        limit_conn conn_limit 10;

        # JWT validation (using auth_request)
        auth_request /auth;
        auth_request_set $user_id $upstream_http_x_user_id;

        # Forward to backend
        proxy_pass http://user_service;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-API-Client $api_client_name;
        proxy_set_header X-User-ID $user_id;

        # Hide internal headers
        proxy_hide_header X-Powered-By;
    }

    # Internal auth endpoint
    location = /auth {
        internal;
        proxy_pass http://auth-service:8080/validate;
        proxy_pass_request_body off;
        proxy_set_header Content-Length "";
        proxy_set_header X-Original-URI $request_uri;
        proxy_set_header Authorization $http_authorization;
    }

    # Block common attacks
    location ~* (\.\.\/|\.\.\\|%2e%2e%2f|%2e%2e\/|\.%2e\/|%2e\.\/|\.\.\/) {
        return 403;
    }
}

# /etc/nginx/modsecurity/main.conf
Include /etc/nginx/modsecurity/modsecurity.conf
Include /etc/nginx/modsecurity/crs/crs-setup.conf
Include /etc/nginx/modsecurity/crs/rules/*.conf

# Custom API rules
SecRule REQUEST_URI "@beginsWith /api/" \
    "id:10001,\
    phase:1,\
    pass,\
    nolog,\
    setvar:tx.allowed_methods=GET POST PUT DELETE PATCH"

# Block SQL injection in JSON
SecRule REQUEST_BODY "@rx (?i)(\b(select|insert|update|delete|drop|union|exec)\b)" \
    "id:10002,\
    phase:2,\
    deny,\
    status:403,\
    log,\
    msg:'SQL Injection attempt in request body'"

# Limit JSON depth
SecRule REQUEST_HEADERS:Content-Type "@contains application/json" \
    "id:10003,\
    phase:1,\
    pass,\
    setvar:tx.max_json_depth=10"

{
  "Name": "APISecurityRules",
  "Rules": [
    {
      "Name": "SQLInjectionRule",
      "Priority": 1,
      "Statement": {
        "SqliMatchStatement": {
          "FieldToMatch": {
            "Body": {}
          },
          "TextTransformations": [
            {"Priority": 0, "Type": "URL_DECODE"},
            {"Priority": 1, "Type": "HTML_ENTITY_DECODE"}
          ]
        }
      },
      "Action": {"Block": {}},
      "VisibilityConfig": {
        "SampledRequestsEnabled": true,
        "CloudWatchMetricsEnabled": true,
        "MetricName": "SQLInjection"
      }
    },
    {
      "Name": "XSSRule",
      "Priority": 2,
      "Statement": {
        "XssMatchStatement": {
          "FieldToMatch": {
            "Body": {}
          },
          "TextTransformations": [
            {"Priority": 0, "Type": "URL_DECODE"},
            {"Priority": 1, "Type": "HTML_ENTITY_DECODE"}
          ]
        }
      },
      "Action": {"Block": {}},
      "VisibilityConfig": {
        "SampledRequestsEnabled": true,
        "CloudWatchMetricsEnabled": true,
        "MetricName": "XSS"
      }
    },
    {
      "Name": "RateLimitRule",
      "Priority": 3,
      "Statement": {
        "RateBasedStatement": {
          "Limit": 2000,
          "AggregateKeyType": "IP"
        }
      },
      "Action": {"Block": {}},
      "VisibilityConfig": {
        "SampledRequestsEnabled": true,
        "CloudWatchMetricsEnabled": true,
        "MetricName": "RateLimit"
      }
    }
  ]
}

# Prometheus alerting rules
groups:
  - name: api-gateway-alerts
    rules:
      - alert: HighErrorRate
        expr: |
          sum(rate(api_requests_total{status=~"5.."}[5m]))
          / sum(rate(api_requests_total[5m])) > 0.05
        for: 5m
        labels:
          severity: critical
        annotations:
          summary: "API error rate above 5%"

      - alert: HighLatency
        expr: |
          histogram_quantile(0.95,
            sum(rate(api_request_duration_seconds_bucket[5m])) by (le)
          ) > 2
        for: 5m
        labels:
          severity: warning
        annotations:
          summary: "95th percentile latency above 2 seconds"

      - alert: RateLimitExceeded
        expr: |
          sum(rate(api_rate_limit_exceeded_total[5m])) > 100
        for: 1m
        labels:
          severity: warning
        annotations:
          summary: "High rate of rate-limited requests"

      - alert: AuthenticationFailures
        expr: |
          sum(rate(api_auth_failures_total[5m])) > 50
        for: 5m
        labels:
          severity: warning
        annotations:
          summary: "High authentication failure rate"
